Regular price
Rs. 2,684.15
Sale price
Rs. 2,684.15
Regular price
Unit price
per
Couldn't load pickup availability
Low stock! Only 1 left
Specifications
| Cleanroom suitability | Class 6 (ISO 14644-1) |
| Conforms to standard | ISO 6432 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Design | Piston, Piston rod, Cylinder barrel |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Mode of operation | Double-acting |
| Mounting position | Optional |
| Note on operating and pilot medium | Lubricated operation possible (then lubrication always required) |
| Operating medium | Compressed air (ISO 8573-1:2010 [7:4:4]) |
| Operating pressure (MPa) | 0.1 ... 1 |
| Operating pressure (bar) | 1 ... 10 |
| Piston diameter | 25 mm |
| Piston rod thread | M10x1.25 |
| Piston-rod end | Male thread |
| Position detection | Via proximity switch |
| Stroke | 200 mm |
| Symbol | 991235.0 |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 294.5 N |
| Variants | Piston rod at one end |
